PODNOŽJE: AMD FM2+
ZA PROCESORJE: AMD FM2+ Athlon & A-series APU
FORMAT: ATX Form Factor 24.4 cmx24.4 cm
VEZNI EIP: AMD A88X
POMNILNIK:
4x1.5V DDR3 DIMM (2400(OC)/2133/1866/1600/1333MHz) do skupno 64GB kapacitete, dual channel podpora
GRAFIKA: DA (le preko AMD APU) Maximum shared memory of 2GB
RAID: DA (0,1,5,10,JBOD)
RAZŠIRITVENE REŽE:
1xPCI Express x16 Slot (x16 mode)
1xPCI Express x16 Slot (x4 mode)
1xPCi Express x1
1xPCI Slot
MREŽNA KARTICA: Realtek LAN chip (10/100/1000Mbit)
ZVOENA KARTICA: Realtek ALC887 codec High Definition Audio (2/4/5.1/7.1channel)
NOTRANJI PRIKLJUEKI:
1x24-pin ATX main power connector
1x8-pin ATX 12V power connector
8xSATA 6Gb/s connectors
1xAPU fan header
2xsystem fan headers
1xfront panel header
1xfront panel audio header
1xS/PDIF Out header
1xUSB 3.0/2.0 header
2xUSB 2.0/1.1 headers
1xserial port header
1xparallel port header
1xClear CMOS jumper
1xTrusted Platform Module (TPM) header
ZUNANJI PRIKLJUEKI:
1xPS/2 keyboard/mouse port
1xD-Sub port
1xDVI-D port
1xHDMI port
2xUSB 3.0/2.0 ports
1xUSB 3.1 Type-A port (red)
1xUSB Type-C™ port, with USB 3.1 support
4xUSB 2.0/1.1 ports
1xRJ-45 port
3xaudio jacks (Line In, Line Out, Mic In)
DODATNO:
iTE® I/O Controller Chip
H/W Monitoring
System voltage detection
APU/System temperature detection
APU/System fan speed detection
APU overheating warning
APU/System fan fail warning
APU/System fan speed control
BIOS
2x64 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center
@BIOS
Cloud Station
EasyTune
Smart TimeLock
Game Controller
Smart Recovery 2
System Information Viewer
USB Blocker
Support for Q-Flash
Support for ON/OFF Charge
Support for Smart Switch
Support for Xpress Install
Bundle Software
Norton® Internet Security (OEM version)
Spletna stran proizvajalca: http://www.gigabyte.si/products/product-page.aspx?pid=5657#ov
